Table 9B — Electrical Data — 50BVT,U,V,W,X
LEGEND
UNIT SIZE
50BVT,U,V,W,X
NOMINAL
VOLTAGE
(3 Ph, 60 Hz)
VOLTAGE
RANGE
COMPRESSOR
INDOOR FAN MOTOR
POWER
SUPPLY
DISCONNECT
SIZE
No. 1 / No. 2
No. 3 / No. 4
Min
Max
RLA
LRA
RLA
LRA
Qty
HP
(ea)
FLA
(ea)
MCA
MOCP
FLA
034
208/230
187
253
62.2
376
—
—
1
7.5
19.4
159.4
200
143.8
10
25.8
165.8
225
150.2
15
38.6
178.6
225
163.0
20
49.6
189.6
250
174.0
460
414
506
27.6
178
—
—
1
7.5
9.7
71.8
90
64.9
10
12.9
75.0
100
68.1
15
19.3
81.4
100
74.5
20
24.8
86.9
110
80.0
575
518
633
20.5
148
—
—
1
7.5
7.8
53.9
70
48.8
10
10.3
56.4
70
51.3
15
15.4
61.5
80
56.4
20
19.8
65.9
80
60.8
044
208/230
187
253
42.0
239
42.0
239
2
7.5
19.4
217.3
250
206.8
10
25.8
230.1
250
219.6
15
38.6
255.7
250
245.2
460
414
506
19.2
125
19.2
125
2
7.5
9.7
101.0
110
96.2
10
12.9
107.4
125
102.6
15
19.3
120.2
125
115.4
575
518
633
12.4
80
12.4
80
2
7.5
7.8
68.3
80
65.2
10
10.3
73.3
80
70.2
15
15.4
83.5
90
80.4
054
208/230
187
253
47.1
318
47.1
318
2
7.5
19.4
239.0
250
227.2
10
25.8
251.8
250
240.0
15
38.6
277.4
300
265.6
20
49.6
299.4
300
287.6
460
414
506
22.6
158
22.6
158
2
7.5
9.7
115.5
125
109.8
10
12.9
121.9
125
116.2
15
19.3
134.7
150
129.0
20
24.8
145.7
150
140.0
575
518
633
17.3
125
17.3
125
2
7.5
7.8
89.1
100
84.8
10
10.3
94.1
110
89.8
15
15.4
104.3
110
100.0
20
19.8
113.1
125
108.8
064
208/230
187
253
62.2
376
62.2
376
2
7.5
19.4
303.2
350
287.6
10
25.8
316.0
350
300.4
15
38.6
341.6
400
326.0
20
49.6
363.6
400
348.0
460
414
506
27.6
178
27.6
178
2
7.5
9.7
136.7
150
129.8
10
12.9
143.1
150
136.2
15
19.3
155.9
150
149.0
20
24.8
166.9
175
160.0
575
518
633
20.5
148
20.5
148
2
7.5
7.8
102.7
110
97.6
10
10.3
107.7
125
102.6
15
15.4
117.9
125
112.8
20
19.8
126.7
125
121.6
FLA
— Full Load Amps
MCA
— Minimum Circuit Amps
HP
— Horsepower
MOCP — Maximum Overcurrent Protection
LRA
— Locked Rotor Amps
RLA
— Rated Load Amps
