Note:
The controller will only find a firmware
update on an SD memory card when it is
stored on the first level of the SD card.

Starting the logging

Insert the SD card into the slot

Adjust the desired logging type and interval

Logging will start immediately.

Stop the logging

Select the menu item Remove card...

After Remove card is displayed, remove the
card from the slot

When Linear is adjusted in the adjustment channel
Logging type, data logging will stop if the capacity
limit is reached. The message Card full will be dis-
played.
If Cyclic is adjusted, the oldest data logged onto the
SD card will be overwritten as soon as the capacity
limit is reached.

Note:
Because of the increasing size of the data
packets, the remaining logging time does not
decrease linearly. The data packet size can
increase, e. g. with the increasing operating
hours value.

Note:
To safely remove the SD card, always select
the menu item Remove card... before re-
moving the card.

Storing controller adjustments

To store the controller adjustments on an SD
card, select the menu item Save adjustments.

While the adjustments are being stored, first Please
wait, then Done! will be indicated on the display. The
controller adjustments are stored as a .SET file on
the SD card.

Loading controller adjustments

To load controller adjustments from an SD card,
select the menu item Load adjustments.

The File selection window is indicated.

Select the desired .SET file.

While the adjustments are being loaded, first Please
wait, then Done! will be indicated on the display.

Formatting the SD card

Select the menu item Format card

The content of the card will be deleted and the card
will be formatted with the FAT file system.

Adjustment channel

Description

Adjustment range / selection Factory setting

Remove card...

Safely remove card

Save adjustments

Load adjustments

Logging interval

00:01 ... 20:00 (mm:ss)

01:00

Logging type

Cyclic, Linear

Linear

Format card

SD card
