Ink Film

■ Changing the film (KX-FA136A)

^ Open the cover by pressing the cover open button.

Remove the film cartridge.

Unlock the four gears by (®) pulling the top side
gears (blue and green gears) forward and (d))
lifting up the bottom side gears (green gears).

Remove the used film.

Film cartridge

Blue gear

side gears

Bottom side gears

Green gear

Caution;

• The film i

page 12.

Insert the blue gear into the blue core of the new

film.

■o
