Tables 5, 6 and 7 are sample Parameter Tables for Network B.
Table 5 Sample Parameter Table for New York
One-Touch/
ABBR No.
Station Name
Telephone
Number
Relay
Address
Relay
Station
YES/NO
Network
Address
One
Station
XMT
New York 212 1111234 — — 1000
01 London 011 44 1 1111234 20 YES 2000 Direct
02 Stockholm 011 46 8 1111234 20 NO 2001 Direct
03 Geneva 011 41 22 1111234 20 NO 2002 Direct
04 Rome 011 39 6 1111234 20 NO 2003 Direct
05 Singapore 011 65 1111234 20 NO 3000 Direct
06 Tokyo oil 81 3 1111234 20 NO 3001 Relay
07 Hong Kong Oil 852 5 1111234 20 NO 3002 Relay
08 Sydney 011 61 2 1111234 20 NO 3003 Relay
09 Wellington 011 64 4 1111234 20 NO 3004 Relay
Table 6 Sample Parameter Table for London
One-Touch/
ABBR No.
Station Name
Telephone
Number
Relay
Address
Relay
Station
YES/NO
Network
Address
London 1 111 1234 20 — 2000
01 Stockholm 010 46 8 1111234 20 NO 2001
02 Geneva 010 41 22 1111234 20 NO 2002
03 Rome 010 39 6 1111234 20 NO 2003
04 Singapore 010 65 1111234 30 YES 3000
05 Tokyo 010 81 3 1111234 30 NO 3001
06 Hong Kong 010 852 5 1111234 30 NO 3002
07 Sydney 010 61 2 1111234 30 NO 3003
08 Wellington 010 64 4 1111234 30 NO 3004
09 New York 010 1 516 1111234 — — 1000
Table 7 Sample Parameter Table for Singapore
One-Touch/
ABBR No.
Station Name
Telephone
Number
Relay
Address
Relay
Station
YES/NO
Network
Address
Singapore 1111234 30 — 3000
01 Tokyo 005 81 3 1111234 30 NO 3001
02 Hong Kong 006 852 5 1111234 30 NO 3002
03 Sydney 005 61 2 1111234 30 NO 3003
04 Wellington 005 64 4 1111234 30 NO 3004
05 New York 005 1 212 1111234 — — 1000
102
Setting Up Your Machine for Relayed Transmission
To set up your machine for Relayed Transmission, use the procedures on the following
pages to set the eight parameters listed below. Some parameters (e.g., Relayed XMT
Fax Parameter) are only set once, but others must be set separately for each station
in the Relay Network.
1. Relayed XMT Fax Parameter;
This switches the Relayed XMT function ON or OFF.
2. Own Telephone Number:
The full telephone number should be entered.
3. Network Address;
End Receiving station telephone numbers set in an Initial Sending station may be
different from the numbers set in a Relay Station. To send a fax to an End Receiving
station via a Relay Station each station in the network must be identified with a certain
code which does not vary depending on where you call from. The code is the Network
Address, which consists of a four-digit number and is assigned to a One-Touch/ABBR
number.
4. Network Password:
A four-digit number which prevents unauthorized (outside) stations from accessing
the Relay Station and using its memory. Every station in the network should set the
same Network Password.
5. One-Touch/ABBR Numbers:
The One-Touch or ABBR number you set must represent the fax number of a particular
station in the network as seen from your station.
6. Relay Station Parameter (Yes/No):
Set ‘‘Yes*’ if the particular station you are recording is a Relay Station. If you are
connected to more than one Relay Station in series, set “YES” only for the first Relay
Station.
7. Relay Address:
A two-digit number which identifies the Relay Station your machine will use. Your
machine may be connected to more than one Relay Station in parallel, but when
you use Relayed XMT your machine will only send documents to the Relay Station
identified by the Relay Address.
8. One Station XMT (Relay/Dlrect) Parameter;
If you send a document to only one End Receiving Station, you can set your machine
to transmit directly to that station, without going through the Relay Station, by selecting
“Direct.” Set “Relay” if you always want to go through the Relay Station.
103
