Specifications
NV-J45A, EA
information for Your Safety
Power Source:
Power Consumption;
NV-J45A; 240 V AC 50-60 Hz
NV-J45EA; 230 V AC 50-60 Hz
Approx. 24 watts
Video Recording System:
Video Heads:
Tape Speed:
Tape Format;
Record/Playback Time:
FF/REW Time:
VIDEO
Television System:
Modulation System:
Input Level:
Output Level:
AUDIO
Input Level:
Output Level:
Audio Track:
Video Horizontal Resolution:
Signal-to-Noise Ratio;
Audio Frequency Response:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
Standard Accessories;
2 rotary heads, helical scanning system
4 heads
SP; 23.39 mm/sec.
LP; 11.7 mm/sec.
VHS tape
SP: 240 min. with NV-E240(VHS)
LP; 480 min. with NV-E240(VHS)
Approx. 2.5 min. with NV-E180
CCIR; 625 lines, 50 fields, PAL colour signal
Luminance: FM azimuth recording
Colour signal: converted subcarrier phase shift recording (PAL, CCIR)
VIDEO IN (PHONO):
VIDEO OUT (PHONO);
RF Modulated; NV-J45A;
NV-J45EA;
AUDIO IN (PHONO):
MICROPHONE:
AUDIO OUT (PHONO):
1 track (Normal-mono only)
Colour; more than 240 lines (SP)
Video; more than 43 dB (SP)
Audio; more than 43 dB (SP)
80 Hz-10 kHz (SP)
5X-40“C
35%-80%
5.0 kg
380 (W)x82 (H)x344.5 (D) mm
1 pc. DIN-DIN Coaxial Cable
1 pc. Remote Controller
2 pcs. ‘‘R6’’ size batteries
1 pc. AC Mains Lead
1.0 Vp-p,
1.0 Vp-p,
VHF channel 0 or 1,
VHF channel 2 or 3,
-10 dB,
-70 dB,
-6dB,
75 ohm, terminated
75 ohm, terminated
75 ohm, unbalanced
75 ohm, unbalanced
more than 50 kohm, unbalanced
more than 600 ohm
less than 1 kohm, unbalanced
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
