Playback (Cont’d)
DIGITAL TRACKING Noise Filter/Edit Selector
ON
'E195
OFF
TAPE SELECT
TRACKING/V-LOCK
E240
EDIT ON; For editing operations such as dubbing,
OFF: For ordinary use of the VTR.
NOISE FILTER ON: For playback of tapes with inferior
picture quality caused, for example, by repeated dubbing.
z'------------------------------------------------------------------------------
• When the Noise Filter/Edit Selector is set to "EDIT
ON", the picture sharpness cannot be adjusted
with the Picture Sharpness Control.
Tape Select Switch
To obtain a correct Remaining Tape Time indication when
using an NV-E240 video cassette tape, this switch must
be set to the “E240" position.
When using NV-E30, 60, 90, 120, 180 or 195 video
cassette tapes, set this switch to the “~E195” position.
If cassettes with other tape lengths than the above are
used, the Remaining Tape Time indication will not be
precise.
Digital Tracking
When playback is started after inserting a cassette, and
the VTR is turned on, the Digital Tracking function will be
activated automatically, the Digital Tracking Indicator will
flash for several seconds, and the tracking will be adjusted
automatically (after the adjustment, the Digital Tracking
Indicator will remain lit).
• When the Digital Tracking Indicator is lit and the tape
speed (SP/LP) is changed, the Digital Tracking function
will be activated. However, when operating any function
other than playback, insert editing and audio dubbing,
this function will not work.
• During playback, the Digital Tracking function will be
activated whenever the playback changes over from an
unrecorded part to a recorded part, provided the
recorded part is longer than 4 seconds.
• When the picture is distorted by noise bars, press
the Tracking “ + ” or Button to select manual
tracking and adjust with these two buttons. The
Digital Tracking Indicator goes out.
To change back to Digital Tracking, press the
Tracking “ + and Buttons simultaneously.
Vertical Lock Adjustment * •
If vertical jitter occurs, adjust with the V-Lock or
Button during Still playback,
• When the AC Mains Lead is unplugged or a power failure
occurs, perform the vertical lock adjustment again.
< 19 )
