Page 7

Step 1

Step 2

40218
8x12x0.3mm
Washer

.....x2

ASSEMBLY OF THE CENTER DIFF.

30776
4x10x0.15mm
Washer

.....x8

30773
4mm Cross Pin

.....x2

36053
8x16x5mm
Ball Bearing

94034
4x4mm
Set Screw

40010
2.5x13.8mm Pin

.....x2

.....x1

40009
P6 O-Ring

94020
3x12mm
Flat Head
Hex Screw

.....x4

Step detail

Step 1

Step 2

Step detail

Repeat tightening in this order

After assembly the differential should be 35.6~35.7mm
measured from the ends of the installed ball-bearings.
If differential is longer, holding the bevel gear and
retighten the 4 screws.

Oil

30773

40513

30776

Step 3

Use the Diff. Oil #5000 for the center diff.

Step 4

Step 2

Step 1

Step 5

Oil

40514

36053

40010

40513

40009

40538

Oil

40513

40010

40009

36053

40514

8x12x0.3mm

41210

40011

3x12mm

4x4mm

Tighten

8x12x0.3mm

80%

Fill the diff oil just level with the
top of the satellite gears.

Step detail
