41

ASSEMBLY OF THE REAR GEAR CASE ONTO CHASSIS

39

40

FILL THE GREASE INTO THE GEAR CASE

ASSEMBLY OF THE FRONT GEAR CASE ONTO CHASSIS

GEAR

GREASE

GEAR

GREASE

Lightly coat the ring and pinion
gear with gear grease.
Part number10240

94027
4x16mm
Flat Head Hex Screw

.....x4

94026
4x12mm
Flat Head Hex Screw

.....x2

94019
3x10mm
Flat Head
Hex Screw

.....x2

3x10mm

4x12mm

4x16mm

ew

Scr

Cem

ent

Tighten

94027
4x16mm
Flat Head Hex Screw

.....x4

94019
3x10mm
Flat Head
Hex Screw

.....x2

3x10mm

4x16mm

Tighten

41201
