67

ASSEMBLY OF THE SHOCKS SPRING

Step 1

Step 2

Step 3

Cut 7mm

40058

41027(SHORT)

41008

41008

41022(LONG)

Step 1

Step 2

REAR SHOCK

FRONT SHOCK

40058

66

SETTING THE SHOCK REBOUND TO 50% & 0%
(MEDIUM REBOUND & LOW REBOUND)

Step 1

Step 2

TIGHTENED HALF WAY 50%

50%

TIGHTENED 100%

50%

Step 3

Step 1

Step 2

Step 3

65

SETTING THE SHOCK REBOUND TO 100% (HIGH REBOUND)

Assemble both left and right sides.

SHOC

K O L

I

Step detail

Step 1

Step 2

Step 5

Step 3

Step 4

41013

41005

FRONT (SHORT ) SHOCKS OIL #40

REAR (LONG ) SHOCKS OIL #50

3~5x

UP & DOWN

Step 6

TIGHTENED HALF WAY 50%

TIGHTENED 100%

•Leave the filled shock vertically for several
minutes with the shock shaft fully extended.

•The remaining air bubbles will release.

Time

TIGHTENED HALF WAY 50%

TIGHTENED 100%
