SmartSwitch Router User Reference Manual
59
Chapter 6: Packet-over-SONET Configuration Guide
2.
Create a point-to-point interface with the interface create command, specifying the IP
address and netmask for the interface on the SSR and the peer address of the other
end of the connection:
When you create the point-to-point interface as shown above, the SSR creates an
implicit VLAN called “SYS_L3_
creates the VLAN ‘SYS_L3_pos11.’
3.
If you want to increase the MTU size on a port, specify the parameter mtu with the
‘port set’ command and define a value up to 65535 (octets). See
for more information.
4.
Specify the bit error rate thresholds, if necessary. See
for more information.
5.
Modify any other PoS operating parameters, as needed. The following table lists the
operating parameters that you can modify and the configuration commands that you
use.
Configuring Automatic Protection Switching
Automatic protection switching (APS) provides a mechanism to support redundant
transmission circuits between SONET devices. The SSR supports the following APS
features:
•
Linear network topology. Ring topologies are not supported.
•
1+1 switching. Each working line is protected by one protecting line and the same
signal is transmitted on both the working and protecting lines. The two transmission
copies that arrive at the receiving end are compared, and the best copy is used. If there
is a line failure or line degradation, the end node switches the connection over to the
protecting line.
interface create ip pos11 address-netmask 20.11.11.20/24 peer-address
20.11.11.21 port so.13.1
Table 4: PoS Optional Operating Parameters
Parameter
Default Value
Configuration Command
Framing
SONET
sonet set
Loopback
Disabled
sonet set
Path tracing
(none)
sonet set
Circuit identifier
(none)
sonet set
Frame Check Sequence
32-bit
sonet set
Scrambling
Enabled
sonet set
