Chapter 20: Security Configuration Guide
280
SmartSwitch Router User Reference Manual
A secure filter shuts down access to the SSR based on MAC addresses. All packets
received by a port are dropped. When combined with static entries, however, these
filters can be used to drop all received traffic but allow some frames to go through.
Configuring Layer-2 Address Filters
If you want to control access to a source or destination on a per-MAC address basis, you
can configure an address filter. Address filters are always configured and applied to the
input port. You can set address filters on the following:
•
A source MAC address, which filters out any frame coming from a specific source
MAC address
•
A destination MAC address, which filters out any frame destined to specific
destination MAC address
•
A flow, which filters out any frame coming from a specific source MAC address that is
also destined to a specific destination MAC address
To configure Layer-2 address filters, enter the following commands in Configure mode:
Configure a source MAC based
address filter.
filters add address-filter name
source-mac
source-mac-
mask
vlan
in-
port-list
Configure a destination MAC based
address filter.
filters add address-filter name
dest-mac
dest-mac-mask
vlan
in-port-
list
Configure a Layer-2 flow address
filter.
filters add address-filter name
source-mac
source-mac-
mask
dest-mac
dest-mac-mask
vlan
num>
in-port-list
