SmartSwitch Router User Reference Manual 319
Chapter 23: RMON Configuration Guide
following command:
Configuring RMON Groups
As mentioned previously, control tables in many RMON groups specify the data that is to
be collected for the particular RMON group. If the information you want to collect is in
the default control tables, then you only need to turn on the default tables when you
specify the RMON groups (Lite, Standard, or Professional); you do not need to configure
entries in the default tables.
The following table shows the rmon command that you use to configure each RMON
group:
ssr# rmon show al-matrix et.5.5
RMON II Application Layer Host Table
Index: 500, Port: et.5.5, Inserts: 4, Deletes: 0, Owner: monitor
SrcAddr DstAddr Packets Octets Protocol
------- ------- ------- ------ --------
10.50.89.88 15.15.15.3 1771 272562 *ether2.ip-v4
10.50.89.88 15.15.15.3 1125 211192 *ether2.ip-v4.tcp
10.50.89.88 15.15.15.3 1122 210967 *ether2.ip-v4.tcp.telnet
10.50.89.88 15.15.15.3 3 225 *ether2.ip-v4.tcp.www-http
To configure the Address
Map group. rmon address-map index port
[owner ] [status enable|disable]
To configure the Application
Layer Matrix top n entries. rmon al-matrix-top-n index matrix-
index ratebase terminal-packets|terminal-
octets|all-packets|all-octets duration size
[owner ] [status enable|disable]
To configure the Alarm
group. rmon alarm index variable
[interval ] [falling-event-index ]
[falling-threshold ] [owner ] [rising-
event-index
] [rising-threshold ]
[startup rising|falling|both] [status enable|disable]
[type absolute-value|delta-value]
To configure the Packet
Capture group. rmon capture index channel-
index [full-action lock|wrap] [slice-size
] [download-slice-size ]
[download-offset ] [max-octets ]
[owner ] [status enable|disable]
