SmartSwitch Router User Reference Manual 33
Chapter 3: Bridging Configuration Guide
Monitoring Bridging
The SSR provides display of bridging statistics and configurations contained in the SSR.
To display bridging information, enter the following commands in Enable mode.
Configuration Examples
VLANs are used to associate physical ports on the SSR with connected hosts that may be
physically separated but need to participate in the same broadcast domain. To associate
ports to a VLAN, you must first create a VLAN and then assign ports to the VLAN. This
section shows examples of creating an IP or IPX VLAN and a DECnet, SNA, and
AppleTalk VLAN.
Creating an IP or IPX VLAN
In this example, servers connected to port gi.1.(1-2) on the SSR need to communicate with
clients connected to et.4.(1-8). You can associate all the ports containing the clients and
servers to an IP VLAN called ‘BLUE’.
First, create an IP VLAN named ‘BLUE’
Next, assign ports to the ‘BLUE’ VLAN.
Show IP routing table. ip show routes
Show all MAC addresses currently
in the l2 tables. l2-tables show all-macs
Show l2 table information on a
specific port. l2-tables show port-macs
Show information the master MAC
table. l2-tables show mac-table-stats
Show information on a specific
MAC address. l2-tables show mac
Show information on MACs
registered. l2-table show bridge-management
Show all VLANs. vlan show
ssr(config)# vlan create BLUE ip
ssr(config)# vlan add ports et.4.(1-8),gi.1.(1-2) to BLUE
