Chapter 14: Multicast Routing Configuration Guide
204 SmartSwitch Router User Reference Manual
Configuration Examples
The following is a sample SSR configuration for DVMRP and IGMP. Seven subnets are
created. IGMP is enabled on 4 IP interfaces. The IGMP query interval is set to 30 seconds.
DVMRP is enabled on 5 IP interfaces. IGMP is not running on “downstream” interfaces.
Shows all IGMP group
memberships on a port basis. igmp show memberships
Show all IGMP timers. igmp show timers
Show information about multicasts
registered by IGMP. l2-tables show igmp-mcast-registration
Show IGMP status on a VLAN. l2-tables show vlan-igmp-status
Show all multicast Source, Group
entries. mulitcast show cache
Show all interfaces running
multicast protocols (IGMP,
DVMRP). multicast show interfaces
Show all multicast routes. multicast show mroutes
! Create VLANS.
!
vlan create upstream ip
vlan add ports et.5.3,et.5.4 to upstream
!
! Create IP intefaces
!
interface create ip mls15 address-netmask 172.1.1.10/24 port et.5.8
interface create ip company address-netmask 207.135.89.64/25 port et.5.1
interface create ip test address-netmask 10.135.89.10/25 port et.1.8
interface create ip rip address-netmask 190.1.0.1 port et.1.4
interface create ip mbone address-netmask 207.135.122.11/29 port et.1.1
interface create ip downstream address-netmask 10.40.1.10/24 vlan upstream
!
! Enable IGMP interfaces.
!
igmp enable interface 10.135.89.10
igmp enable interface 172.1.1.10
igmp enable interface 207.135.122.11
igmp enable interface 207.135.89.64
!
! Set IGMP Query Interval
!
igmp set queryinterval 30
!
! Enable DVMRP
!
dvmrp enable interface 10.135.89.10
