SmartSwitch Router User Reference Manual 53
ATM Sample Configuration 1
Configuring an Interface on an Ethernet Port
There are two separate VLANs in this network, VLAN A and VLAN B. VLAN A is
connected to Ethernet port et.2.1 on SSR1, and VLAN B is connected to Ethernet port et.1.1
on SSRSSR2.
Apply an interface on both Ethernet ports. Creating an interface on an Ethernet port
assigns a network IP address and submask on that port.
Creating a Virtual Channel
Create a VC to connect ATM port at.1.1 on SSR1 to ATM port at.2.1 on SSR2. Use the
following command to create a virtual channel on SSR1 with vpi=0 and vci=100:
You must now configure a corresponding vpi/vci pair on ATM port at.2.1. Use the
following command to create a virtual channel on SSR2 with vpi=0 and vci=100:
Note that you are using the same vpi and vci on both SSRs. This establishes a common VC
from one ATM port to another ATM port.
Defining an ATM Service Class
After creating a VC connection from ATM port at.1.1 to at.2.1, the next step is to define an
ATM service class for this connection.
The following command lines defines a service class named ‘cbr1m’ on both SSR1 and
SSR2 where CBR is the service category and peak cell rate is set to 10000 kcells/second:
ssr1(config)# atm create vcl port at.1.1.0.100
ssr2(config)# atm create vcl port at.2.1.0.100
ssr1(config)# atm define service cbr1m srv-cat cbr pcr-kbits 10000
ssr2(config)# atm define service cbr1m srv-cat cbr pcr-kbits 10000
