Technische Daten

Elektrische Daten

Versorgungsspannung U

B

Spannungstoleranz

Leistungsaufnahme bei U

B

Restwelligkeit

Spannung und Strom an

Eingangskreis
Start- und Rückführkreis

Anzahl der Ausgangskontakte

Sicherheitskontakte (S)
Hilfskontakte (Ö)

Gebrauchskategorie nach

EN 60947-4-1

EN 60947-5-1(DC13:
6 Schaltspiele/Min.)

Kontaktmaterial

Kontaktabsicherung extern
EN 60947-5-1 (I

K

= 1 kA)

Schmelzsicherung flink
Schmelzsicherung träge
Sicherungsautomat
Charakteristik

Max. Gesamtleitungswiderstand R

lmax

Eingangskreise

einkanalig DC

Sicherheitstechnische Kenndaten
der Sicherheitsausgänge

PL nach EN ISO 13849-1

Kategorie nach EN 954-1

SIL CL nach EN IEC 62061

PFH nach EN IEC 62061

SIL nach IEC 61511

PFD nach IEC 61511

t

M

in Jahren

Zeiten

Einschaltverzögerung

Automatischer Start
Manueller Start

Rückfallverzögerung

bei Not-Halt
bei Netzausfall

Wiederbereitschaftszeit bei max.
Schaltfrequenz 1/s

nach Not-Halt
nach Netzausfall

Gleichzeitigkeit Kanal 1 und 2

Überbrückung bei
Spannungseinbrüchen

Umweltdaten

EMV

Schwingungen nach EN 60068-2-6

Frequenz
Amplitude

Klimabeanspruchung

Luft- und Kriechstrecken nach
EN 60947-1
Verschmutzungsgrad
Überspannungskategorie

Bemessungsisolationsspannung

Bemessungsstoßspannungs-
festigkeit

Umgebungstemperatur

DC: 24 V

-15 ... +10 %

1,5 W

DC: 160 %

24 V DC: 45 mA

24 V DC: 45 mA

3
1

AC1: 240 V/0,01 ... 6 A/
1500 VA
DC1: 24 V/0,01 ... 6 A/
150 W
AC15: 230 V/5 A;
DC13: 24 V/4 A

AgSnO

2

+ 0,2 µm Au

6 A
4 A
24 V AC/DC: 4 A
B/C

30 Ohm

PL e (Cat. 4)

Cat. 4

SIL CL 3

2,31E-09

SIL 3

2,03E-06

20

typ. 60 ms, max. 120 ms
typ. 50 ms, max. 120 ms

typ.: 55 ms, max.: 90 ms
typ.: 55 ms, max.: 90 ms

150 ms
150 ms

20 ms

EN 60947-5-1,
EN 61000-6-2

10 ... 55 Hz
0,35 mm

EN 60068-2-78

2
III

250 V

4 kV

-10 ... + 55 °C

Technical Data

Electrical data

Supply Voltage U

B

Voltage Tolerance

Power consumption at U

B

Residual Ripple

Voltage and Current at

Input circuit
Reset circuit and feedback loop

Number of output contacts

Safety contacts (N/O)
Auxiliary contacts (N/C)

Utilization category in accordance with

EN 60947-4-1

EN 60947-5-1(DC13: 6 cycles/min)

Contact material

External contact fuse protection
EN 60947-5-1 (I

K

= 1 kA)

Blow-out fuse quick
Blow-out fuse slow
Safety cut-out
Cvaracteristic

Max. overall cable resistance R

lmax

input circuits

Single-channel DC

Safety-related characteristics of
the safety outputs

PL in accordance with
EN ISO 13849-1

Category in accordance with
EN 954-1

SIL CL in accordance with
EN IEC 62061

PFH in accordance with
EN IEC 62061

SIL in accordance with IEC 61511

PFD in accordance with IEC 61511

t

M

in years

Times

Switch-on delay

Automatic reset
Manual reset

Delay-on De-Energisation

at E-STOP
with power failure

Recovery time at max. switching
frequency 1/s

after E-STOP
after power failure

Simultaneity channel 1 and 2

Supply interruption before de-
energisation

Environmental data

EMC

Vibration to EN 60068-2-6

Frequency
Amplitude

Climate Suitability

Airgap Creepage in accordance with
EN 60947-1
Pollution degree
Overvoltage category

Rated insulation voltage

Rated impulse withstand voltage

Ambient temperature

Caractéristiques techniques

Données électriques

Tension d’alimentation U

B

Plage de la tension d’alimentation

Consommation pour U

B

Ondulation résiduelle

Tension et courant du

Circuit d’entrée
Circuit de réarmement et boucle
de retour

Nombre de contacts de sortie

contacts de sécurité (F)
contact d'info (O)

Catégorie d’utilisation selon

EN 60947-4-1

EN 60947-5-1(DC13:
6 manoeuvres/min)

Matériau contact

Protection des contacts externe
EN 60947-5-1 (I

K

= 1 kA)

Fusibles rapide
Fusibles normal
Dijoncteur
Caractéristique

Résistance de câblage totale max.
R

lmax

circuits d'entrée

Commande par 1 canal DC

Caractéristiques techniques de
sécurité des sorties de sécurité

PL selon EN ISO 13849-1

Catégorie selon EN 954-1

SIL CL selon EN IEC 62061

PFH selon EN IEC 62061

SIL selon IEC 61511

PFD selon IEC 61511

t

M

en années

Temporisations

Temps de réarmement

Réarmement automatique
Réarmement manuel

Temps de retombée

en cas d'arrêt d'urgence
en cas de coupure d'alimentation

Temps de remise en service en cas de
fréquence de commutation max. 1/s

arrêt d'urgence
après une coupure d'alimentation

Désynchronisme canal 1 et 2

Tenue aux micro-coupures

Données sur l'environnement

CEM

Vibrations selon EN 60068-2-6

Frequence
Amplitude

Conditions climatiques

Cheminement et claquage selon
EN 60947-1
Niveau d'encrassement
Catégorie de surtensions

Tension assignée d'isolement

Tension assignée de tenue aux
chocs

Température d’utilisation
