PNOZ s11
Operating Manual PNOZ s11
21693-EN-08
9
Relay outputs
750111
751111
Utilisation category
In accordance with the standard
EN 60947-5-1
EN 60947-5-1
Auxiliary contacts, AC15 at
230 V
230 V
Max. current
5,0 A
5,0 A
Auxiliary contacts, DC13 (6 cy-
cles/min) at
24 V
24 V
Max. current
5,0 A
5,0 A
Safety contacts, AC15 at
230 V
230 V
Max. current
5,0 A
5,0 A
Safety contacts, DC13 (6 cycles/
min) at
24 V
24 V
Max. current
5,0 A
5,0 A
Contact fuse protection, external
safety contacts
In accordance with the standard
EN 60947-5-1
EN 60947-5-1
Blow-out fuse, quick
10 A
10 A
Blow-out fuse, slow
6 A
6 A
Circuit breaker, 24V AC/DC,
characteristic B/C
6 A
6 A
Contact fuse protection, external
auxiliary contacts
Blow-out fuse, quick
10 A
10 A
Blow-out fuse, slow
6 A
6 A
Circuit breaker, 24 V AC/DC,
characteristic B/C
6 A
6 A
Contact material
AgCuNi + 0,2 µm Au
AgCuNi + 0,2 µm Au
Conventional thermal current
while loading several contacts
750111
751111
Ith per contact at UB DC
Conv. therm. current with 1 con-
tact
6,00 A
6,00 A
Conv. therm. current with 2 con-
tacts
6,00 A
6,00 A
Conv. therm. current with 3 con-
tacts
6,00 A
6,00 A
Conv. therm. current with 4 con-
tacts
6,00 A
6,00 A
Conv. therm. current with 5 con-
tacts
6,00 A
6,00 A
Conv. therm. current with 6 con-
tacts
5,70 A
5,70 A
Conv. therm. current with 7 con-
tacts
5,30 A
5,30 A
Conv. therm. current with 8 con-
tacts
5,00 A
5,00 A
