PNOZ s11
Operating Manual PNOZ s11
21693-EN-08
10
Times 750111 751111
Switch-on delay
With automatic reset after power
on typ.
30 ms 30 ms
With automatic reset after power
on max.
50 ms 50 ms
Delay-on de-energisation
With E-STOP typ. 18 ms 18 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 18 ms 18 ms
With power failure max. 30 ms 30 ms
Environmental data 750111 751111
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
EMC EN 60947-5-1, EN 61000-6-2, EN
61000-6-4
EN 60947-5-1, EN 61000-6-2, EN
61000-6-4
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10,0 - 55,0 Hz 10,0 - 55,0 Hz
Max. amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III III
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 6,00 kV 6,00 kV
Protection type
Mounting (e.g. cabinet) IP54 IP54
Housing IP40 IP40
Terminals IP20 IP20
Mechanical data 750111 751111
Mounting position Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles
Material
Bottom PC PC
Front PC PC
Top PC PC
