PNOZ s11
Operating Manual PNOZ s11
21693-EN-08
11
Mechanical data 750111 751111
Cross section of external conduc-
tors with screw terminals
1 core flexible 0,25 - 2,50 mm², 24 - 12 AWG –
2 core with the same cross sec-
tion, flexible with crimp connec-
tors, no plastic sleeve
0,25 - 1,00 mm², 24 - 16 AWG –
2 core with the same cross sec-
tion, flexible without crimp con-
nectors or with TWIN crimp con-
nectors
0,20 - 1,50 mm², 24 - 16 AWG –
Torque setting with screw terminals 0,50 Nm –
Connection type Screw terminal Cage clamp terminal
Mounting type plug in plug in
Cross section of external conduc-
tors with spring-loaded terminals:
flexible with/without crimp connec-
tor
– 0,20 - 2,50 mm², 24 - 12 AWG
Spring-loaded terminals: Terminal
points per connection
– 2
Stripping length – 9 mm
Dimensions
Height 98,0 mm 100,0 mm
Width 45,0 mm 45,0 mm
Depth 120,0 mm 120,0 mm
Weight 335 g 335 g
The standards current on 2009-12 apply.
Safety characteristic data
Operating
mode
EN ISO
13849-1:
2006
PL
EN ISO
13849-1:
2006
Category
EN IEC
62061
SIL CL
EN IEC
62061
PFH
D
[1/h]
IEC 61511
SIL IEC 61511
PFD EN ISO
13849-1:
2006
T
M
[year]
Safety con-
tacts, instan-
taneous
PL e Cat. 4 SIL CL 3 2,31E-09 SIL 3 2,03E-06 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
Information
A safety function's SIL/PL values are
not identical to the SIL/PL values of
the units that are used and may be different. We recommend that you use
the PAScal software tool to calculate the safety function's SIL/PL values.
