PNOZ s6
Operating Manual PNOZ s6
21398-EN-08
15
Mechanical data 750106 750136 751106 751136
Cross section of ex-
ternal conductors
with screw terminals
1 core flexible 0,25 - 2,50 mm², 24
- 12 AWG
0,25 - 2,50 mm², 24
- 12 AWG
– –
2 core with the
same cross sec-
tion, flexible with
crimp connectors,
no plastic sleeve
0,25 - 1,00 mm², 24
- 16 AWG
0,25 - 1,00 mm², 24
- 16 AWG
– –
2 core with the
same cross sec-
tion, flexible with-
out crimp connec-
tors or with TWIN
crimp connectors
0,20 - 1,50 mm², 24
- 16 AWG
0,20 - 1,50 mm², 24
- 16 AWG
– –
Torque setting with
screw terminals
0,50 Nm 0,50 Nm – –
Connection type Screw terminal Screw terminal Spring-loaded ter-
minal
Spring-loaded ter-
minal
Mounting type plug in plug in plug in plug in
Cross section of ex-
ternal conductors
with spring-loaded
terminals: flexible
with/without crimp
connector
– – 0,20 - 2,50 mm², 24
- 12 AWG
0,20 - 2,50 mm², 24
- 12 AWG
Spring-loaded termi-
nals: Terminal points
per connection
– – 2 2
Stripping length – – 9 mm 9 mm
Dimensions
Height 98,0 mm 98,0 mm 100,0 mm 100,0 mm
Width 22,5 mm 22,5 mm 22,5 mm 22,5 mm
Depth 120,0 mm 120,0 mm 120,0 mm 120,0 mm
Weight 185 g 205 g 185 g 205 g
The standards current on 2011-06 apply.
Safety characteristic data
Operating
mode
EN ISO
13849-1:
2006
PL
EN ISO
13849-1:
2006
Category
EN IEC
62061
SIL CL
EN IEC
62061
PFH
D
[1/h]
IEC 61511
SIL IEC 61511
PFD EN ISO
13849-1:
2006
T
M
[year]
Two-hand
function
PL e Cat. 4 SIL CL 3 2,62E-09 SIL 3 3,32E-05 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
