49
MK-2000 Cutting Head, 5.5 HP Honda Part # 170817
ItEM DESCRIPTION PARt # QTY.
1 HANDLE, BRICKSAW 139931 1
2 STUD, BLD GUARD 150581 1
3 STRAP, MOTOR ADJ 150584 1
4 WASH, FLAT, SAE, 3/8 150923 1
5 WASHER, FENDER, 5/16 X 1.0 151053 5
6 BOLT, HEX HD TAP, 5/16-18X2-1/2 151748 4
7 WASHER, FLAT, SAE, 5/16 151754 5
8 WASHER, FLAT, SAE, 1/4 151915 3
9 SCREW, HEX HD, 1/4-20X3/4 152370 2
10 SCREW, HEX HD CAP, 3/8-16 X 1 152507 2
11 WASHER, LOCK, SPLIT, 1/4 152591 2
12 SCREW, 1/4-20 X 1/2 HEX HEAD 152608 1
13 BOLT, 3/8-16 X 4 HEX HEAD TAP 152678 1
14 FITTING, 1/4 MNPT X 1/2 BARB 152704 1
15 ELBOW, 1/4 NPT X 45 STREET 153869 1
16 NUT, HEX, TW, 1/4-20 153941 2
17 NUT, HEX, TW, 5/16-18 153942 5
18 NUT, 1/2-13 HEX 153943 1
19 ASSY, ARBOR, MK-2000 154636 1
20 GRIP, HANDLE 7/8 ID 158608 1
21 SPRING, TORSION, 50 DEG 160071 1
22 GUARD, SPLASH 160310 1
23 SCREW, 5/16-18 X 1-3/4 HEX HEAD MACHINE 160948 1
24 ASSY, MOTOR MOUNT, MK-200 160966 1
25 ASSY, ENGINE, 2000G 170819 1
26 VALVE, BALL 1/4”M X 1/4”F 231248 1
27 CASTING, 2000, BLD GRD-COMP 150579G 1
MK-2000 GAS SAW PART LISTS
