47
MK-2000 GAS SAW PART LISTS
ItEM DESCRIPTION PARt # QTY.
1 WASHER, FLAT, USS, 3/8 101360 1
2 WRENCH, 3/4 BOX END 134056 1
3 COLLAR, 1.13 ODX 625ID .5 WIDE 140012 2
4 WASHER, FLAT, SAE, 3/8 150923 7
5 SCREW, PAN HD, #10-24X3/8 151097 2
6 NUT, HEX, 10-24 151749 2
7 HOSE, VINYL, 1/4X3/8 (32.0’) 152410 1
8 CLAMP, SPRING 152453 1
9 SCREW, HEX HD CAP, 3/8-16 152505 1
10 SCREW, HEX HD 3/8-16 X 1 152507 1
11 SCREW, 3/8-16 X 2-1/4 HEX HEAD 153529 1
12 CLAMP, HOSE, 7/8 154173 2
13 LABEL, MK BRICKSAW 12-1/2X1-3/4 155230 2
14 KNOB, TRI PLASTIC, 1” 156770-01 1
15 TAG, SERIAL NUMBER, BLANK 157500-RW 1
16 SCREW, DRIVE, RND HD, #7X5/16 157849 2
17 SCREW, SHOULDER 3/8 X 1/2 160078 1
18 MASONRY LABEL SHEET (NOT SHOWN) 166011 1
19 BLADE, CG, 14X125X1 10MM 166308 1
20 BAR, BLADE GUARD ADJ. 166602 1
21 BRACKET, HEIGHT ADJUSTMENT 166868 1
22 ASSY, CUTTING HEAD, 5.5 HP HONDA, 14” 170817 1
23 ASSY, FRAME, 2000 170818 1
MK-2000 Saw Assembly Part # 155961
