Split System Operations Chart
OD Ambient (F) Suction (psig) Discharge (psig) Superheat (F) Sub-cooling (F)
10 21 86 3 15
40 25 102 9 16
60 31 105 8 24
70 31 106 12 24
80 32 120 16 21
100 34 164 24 27
115 35 198 28 35
SS050
OD Ambient (F) Suction (psig) Discharge (psig) Superheat (F) Sub-cooling (F)
10 24 86 5 20
40 26 102 5 16
60 28 109 5 17
70 27 114 11 22
80 27 134 13 25
100 27 179 22 30
115 28 215 27 33
SS088
OD Ambient (F) Suction (psig) Discharge (psig) Superheat (F) Sub-cooling (F)
15 22 98 5 15
40 23 95 5 17
60 25 108 8 20
70 27 130 10 22
80 28 146 17 24
100 30 193 20 28
115 33 230 23 30
SS200
OD Ambient (F) Suction (psig) Discharge (psig) Superheat (F) Sub-cooling (F)
15 *25 (avg.) *107 (avg.) *5 (avg.) *11 (avg.)
40 *27 (avg.) *112 (avg.) *5 (avg.) *11 (avg.)
60 28 106 8 5
70 28 123 15 10
80 29 123 13 10
100 30 141 14 10
115 31 210 25 15
Table 4
