37

Procedures for Charging System with Head Pressure Control

(SS025, SS050, SS088)

NOTE: When charging any system with head pressure control the outdoor ambient
temperature must be known.

Charging of Systems with Head Pressure Control in ambients above 70 degrees F (After
normal evacuation procedures):

1. Connect refrigerant cylinder to a charging or gauge port on the receiver outlet valve.

2. Open the receiver valve approximately one-half way (so receiver and liquid line are

connected to charging or gauge port).

3. Charge liquid refrigerant into the high side of the system. Weighing the charge is

recommended.

4. Remove the refrigerant drum and connect it to the suction side of the compressor.

5. Charge refrigerant vapor into the low side. Do not allow liquid refrigerant into the low

side.

6. Start the system.

7. Observe sight glass (at receiver outlet) to see if system is filling with refrigerant for

normal refrigeration cycle.

CAUTION

BUBBLES IN THE

SIGHT GLASS

CAN BE CAUSED BY FLASHING DUE TO PRESSURE DROP FROM

PIPE OR ACCESSORY LOSSES, ETC.

8. If the Sight glass shows bubbles, more refrigerant may be required, while allowing

sufficient time for the refrigerant to stabilize and clear the Sight glass. Use supplied
information on the following pages for proper final charge.

Charging of Systems with Sporlan Head Pressure Control in ambients below 70 degrees F
(After normal evacuation procedures):

NOTE: When charging in ambient below 70 Deg. F the procedure is very critical. Be
sure to adhere to the following steps. Failure to do so will result in overcharging
the system.

1. Follow instructions 1 through 7 above.

2. If the valve setting is correct for the system being charged, it is quite likely that some

refrigerant will be backed up into the condenser and the Sight glass will indicate bubbles
in the liquid line.

3. Add more refrigerant, while allowing sufficient time for the refrigerant to stabilize and

clear the Sight glass. Use supplied information on the following pages for proper final
charge.

4. At this point the system is correctly charged for this type of head pressure control at the

ambient temperature that exists while the charging procedure is taking place.

5. If the system is designed to operate at ambient below the ambient that exits during

charging, additional charge may have to be added now.

Since good system performance during low ambient operation depends on proper refrigerant
charge, it is very important that this phase of the installation procedure be done carefully. Many
times, poor system performance will be due to too little or too much charge. And in many cases,
this will be the last item suspected.
