Quick reference guide, Top view bottom view – Vintage Cellars Mini Ceiling Mount User Manual
Page 4
Page 2 | 1-800-343-9463
MCM
082814
QUICK REFERENCE GUIDE
Top View
Bottom View
Note: The unit comes black. The mounting bracket and front grille
are paintable, enabling you to match your desired color.
Electrical Knockout
Options
Line Set Knockout
Options
Mounting Bracket (Paintable)
Supply and Return Grille (Paintable)
Electrical Knockouts
Line Set
Drain Line
Line Set Knock Out
