Printer Configuration 13
4.2.5 Toledo Interface
Toledo Mode
Off
XON/XOFF must be set to “OFF” during weight extraction when in Toledo Mode.
Note
The checksum must be disabled in the Toledo indicator.
Placement of text may not be identical to the Toledo positions.
A sample printout of the Toledo menu is shown below:
Figure 4-2. Toledo Ticket Example
4.2.6 Print Mode
Print Mode
Standard
Value Action
TicketPress * Alignment at the margin.
SP2200 Alignment with offset.
Note
Note
The TicketPress must be configured for “Weight Extraction” mode when connected to devices
sending data as continuous output.
Submenu of Weight Extraction
WeightEXAlign
WeightExAlign
TicketPress
This menu is only visible when the Weight Extraction mode is set to ON.
Value Action
Off
* No communication with Toledo indicators
On
Allows the TicketPress to communicate with Toledo indicators and format the weight information in both
standard and weight extraction modes.
The expected data format for Weight Extraction mode is as described in Print Mode, below.
Shift In/Shift Out control characters are also supported for control of double-wide printing.
Value Action
Standard
* Data is printed as sent by the host device.
Weight
Extraction
The printer extracts weight, units, and status information from a predefined data input stream.
Please refer to “Weight Extraction” on page 22 for details.
