9.2 Parameter Control Code Chart
Use the following code values for parameter descriptions listed in Table 9.2 when specifying the format string. The
actual character depends on the character mapping used by the output device.
Table 9-2. Parameter Control Code Chart
9.3 Display and Error Messages
Code Description Code Description Code Description
200 Gross weight & LB/KG GR 240 Truck gross lb/kg GR 600 Macro file 1 (7.9)
201 Gross weight & LG/KG 241 Truck gross only 601 Macro file 2 (7.10)
202 Gross weight 242 Truck tare lb/kg TR ↕ ↕ (7.11 – 7.15)
203 Gross weight (no 0 blanking) 243 Truck tare only 607 Macro file 8 (7.16)
244 Truck net lb/kg NT
210 Net weight & LB/KG NT 245 Truck net only 700 Delay per setup
211 Net weight & LN/KN 800 Setpoint 1 & SP1 data
212 Net weight 300 Status character 801 SP1 data only
213 Net weight (no 0 blanking) 400 Time & date per setup 802 Setpoint 2 & SP2 data
401 Time per setup 803 SP2 data only
220 Tare weight & LB/KG TR 402 Date per setup
221 Tare weight & LT/KT 500 Ident no. & ID. NO. 999 End of file
222 Tare weight 501 Ident no. only
223 Tare weight (no 0 blanking) 502 Tag
503 held ID NO. & ID. NO.
230 Total WEIGHT & lb/kg TOTAL 504 Held ID NO. (no label)
231 Total weight & LA/KA 510 TICKET NO. & counter data
232 Total weight only 511 Counter data only
233 Total weight (no 0 blanking)
Display Messages
Display Explanation Corrective Action
Err 1
Err 1a, 1b, 1c Loss of configuration
Loss of option configuration Enter configuration
Enter option mode reconfigure
Err 2 Loss of zero calibration Enter digital calibration mode and recalibrate unit
Err 3 Loss of span calibration
Err 5 Loss of auto tare Acquire tare
Err 6 Loss of auto zero Acquire zero
Err 9 Not in span calibration Program in desired value before entering
Err 10H
Err 10L Input > 3.3mV/V @ full scale
Input < 0.4mV/V @ full scale Recalibrate span so FS ≤ 3.3mV/V
Recalibrate span so FS ≥ 0.4mV/V
Err 10P
Err 10- PTZ (push to zero) > 2.0%
PTZ > weight used for span calibration Perform zero calibration
CAL Indicates successful calibration
OL Gross overload Check load cell wiring
UL Gross underrange
Table 9-3. Display and Error Messages
