42 iQUBE Installation Manual
8.0 920i Serial Commands
The following section lists 920i serial commands used to configure and control the iQUBE . See the 920i
Installation Manual, PN 67887, for more information about using serial commands.
Command Description Values
SJ.SERIAL_NUMBER#n iQUBE serial number Read-only output
SJ.CONFIG#n iQUBE primary-secondary
configuration
8/0/0/0, 4/0/0/0, 4/8/0/0, 4/4/0/0, 4/4/4/0, 4/4/4/4, 8/4/0/0, 8/4/
4/0, 8/8/0/0
SJ.SECT_TYPE#n Section type PAIRED, CIRCULAR
SJ.VERSION.s#n System version Read-only output.
s is the system number, n is the
920i serial port number.
SJ.DUMP#n Dump diagnostic parameters Read-only output.
Dumps all SJ parameters for the
iQUBE connected to port n.
SJ.DOWNLOAD#n Download to iQUBE Downloads configuration and resets iQUBE
n is the. 920i serial port number to which the iQUBE is connected.
Table 8-1. 920i iQUBE Serial Commands
Command Description Values
SJ.LC.ID.c#n Load cell ID Load Cell A1, load_cell_ID (24 characters, maximum)
SJ.LC.SRLNUM.c#n Load cell serial number (16 characters, maximum)
SJ.LC.CAPCTY.c#n Load cell capacity 1–500000
SJ.LC.SENS.c#n Load cell sensitivity 0.0001–9.9999 (mV/V)
SJ.LC.TRIM.c#n Load cell trim factor 0.0001–9.9999
SJ.LC.ZERO.c#n Load cell zero value –0.5 to 45.0
For load cell (SJ.LC.) commands ending with “c#n”, c is the load cell number, n is the 920i serial port number.
Table 8-2. 920i iQUBE Load Cell Serial Commands
Command Description Values
SJ.PLAT.NAME.p#n Platform name Platform1, platform_name (24 characters, maximum)
SJ.PLAT.CELLS.p#n Platform load cells 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 (specify comma-separated list
of load cell numbers associated with this platform) or NONE
(to clear load cell list)
SJ.PLAT.SIM.p#n Platform simulated cell 0, 1–16
SJ.PLAT.WVAL.p#n Platform test weight value 0.0–9999999.0
SJ.PLAT.WSPAN.p#n Platform span calibration –0.5 to 512.0
SJ.PLAT.WLIN.V1.p#n–
SJ.PLAT.WLIN.V5.p#n Platform test weight value for
linearization points 1–5 0.0–9999999.0
SJ.PLAT.WLIN.F1.p#n–
SJ.PLAT.WLIN.F5.p#n Actual raw count value for platform
linearization points 1–5 –0.5 to 512.0
SJ.PLAT.CALTYPE.p#n Platform calibration type NONE, FACTORY, CALMATCH, SECMATCH
SJ.PLAT.CALMULT.p#n Retrieve platform calibration data —
For platform (SJ.PLAT.) commands ending with “p#n”, p is the platform number, n is the 920i serial port number.
Table 8-3. 920i iQUBE Platform Serial Commands
