CLS-920i Installation Manual 51
5.3 Calibration Check
Press the Calibration Check softkey on the 920i to enter in a new calibration weight or keep the existing one if one
has already been entered.
".
$BODFM
4$"-&
MC
&NQ*%
(SPTT
130/VN
#BUUFSZ-JGF )PVST
)PNF &OE
1MFBTFFOUFSUIFUFTUXFJHIU*%
5FTU8U*%
Figure 5-4. Calibration Check Screen
Enter a test weight ID number into the 920i and press enter . You are then asked to Enter Test Weight Amount using the
numeric keypad on the 920i. Enter that amount and press the enter key.
Then the following screen appears.
".
4UPSF/FX
$BM$IFDL
4$"-&
MC
&NQ*%
(SPTT
130/VN
#BUUFSZ-JGF )PVST
&YJU
1SFTTA4UPSF/FX$BM$IFDLPSA&YJUUPBCPSU
Figure 5-5. Store New Calibration Check Screen
Place the test weights on the forks of the scale at this time.
Press the Store New Cal Check softkey to store the new calibration check amount or press Exit to exit out of the
sequence. If the Store New Cal Check softkey is pressed the user is alerted that the New Calibration Check is Stored and
the screen goes back to the Main Menu screen.
