84 920i Installation Manual
Command Description Values
GFMT.FMT
GFMT.PORT Gross demand print format string For .PORT commands, specify the port number as PORTxx (no
leading zero). For example: GFMT.PORT=PORT3.
See Section 6.0 on page 53 for information about demand print
format strings.
See the iQUBE Installation Manual, PN 77224, for more information
about alert formats.
NFMT.FMT
NFMT.PORT Net demand print format string
ACC.FMT
ACC.PORT Accumulator print format string
SPFMT.FMT
SPFMT.PORT Setpoint print format string
TRWIN.FMT
TRWIN.PORT Truck weigh-in print format string
TRWOUT.FMT
TRWOUT.PORT Truck weigh-out print format string
TR.FMT
TR.PORT Truck register print format string
ALERT.FMT
ALERT.PORT Alert format string
HDRFMT1
HDRFMT2 Ticket header format strings
AUXFMT.FMT
AUXFMT.PORT Auxiliary ticket format
WDGT#n Display widget widget_number
See Section 9.2 on page 88 for widget programming information.
WDGT.CLR Clear widgets —
Table 9-7. PFORMT Serial Commands
Command Description
DON.b#s Set digital output on (active) at bit b, slot n.
DOFF.b#s Set digital output off (inactive) at bit b, slot n.
Table 9-8. DIG I/O Serial Commands
Command Description Values
DIO.b#s Digital input function OFF, INPUT, OUTPUT, PROGIN, ZERO, NT/GRS, TARE, UNITS,
PRINT, ACCUM, SETPNT, TIMDATE, ESC, CLEAR, DSPTAR, IDKEY,
KEY0–KEY9, KEYDP, ENTER, NAVUP, NAVDN, NAVLFT, NAVRGT,
KBDLOC, HOLD, BATRUN, BATSTRT, BATPAUS, BATRESET,
BATSTOP, CLRCN, GROSS, NET, PRIM, SEC, CLRTAR, CLRACC
Digital inputs are specified by bit number (b) and slot number (s)
Table 9-9. DIG IN Serial Commands
Command Description Values
ALG.ALIAS#s Analog output alias name
ALG.SOURCE#s Analog output source USER, SCALEn
Table 9-10. ALGOUT Serial Commands (Valid Only If Analog Output Card Is Installed)
