Serial Commands 83
Command Description Values
SP.KIND#n Setpoint kind OFF, GROSS, NET, –GROSS, –NET, ACCUM, ROC, +REL, –REL,
%REL, RESREL, PAUSE, DELAY, WAITSS, COUNTER, AUTOJOG,
COZ, INMOTON, INRANGE, BATCHPR, TIMER, CONCUR, DIGIN,
AVG, TOD, DELTA, CHWEI, PLSCNT, PLSRAT, ALWAYS, NEVER
SP.VALUE#n Setpoint value number
SP.SOURCE#n Source scale SCALE1, SCALE2, SCALE3…SCALEx
SP.TRIP#n Trip HIGHER, LOWER, INBAND, OUTBAND
SP.BANDVAL#n Band value number
SP.HYSTER#n Hysteresis number
SP.PREACT#n Preact type OFF, ON, LEARN, FLOW
SP.PREVAL#n Preact value number
SP.PREADJ#n Preact adjustment percentage number
SP.PRESTAB#n Preact learn stability number
SP.PCOUNT#n Preact learn interval number
SP.TOLBAND#n Target tolerance number
SP.TOLCNT#n Tolerance count number
SP.BATCH#n Batch step enable OFF, ON
SP.CLRACCM#n Clear accumulator enable OFF, ON
SP.CLRTARE#n Clear tare enable OFF, ON
SP.PSHACCM#n Push accumulate OFF, ON, ONQUIET
SP.PSHPRINT#n Push print OFF, ON, WAITSS
SP.PSHTARE#n Push tare OFF, ON
SP.ALARM#n Alarm enable OFF, ON
SP.NAME#n Setpoint name number NONE, 1–60
SP.ACCESS#n Setpoint access OFF, ON, HIDE
SP.SLOT#n Digital output slot number
SP.DIGOUT#n Digital output number
SP.BRANCH#n Branch destination 0, 1-100
SP.RELNUM#n Relative setpoint numer 1–100
SP.START#n Starting setpoint 1–100
SP.END#n Ending setpoint 1–100
SP.DSLOT#n Digital input slot number
SP.MASK#n Digital input mask number
SP.NSAMPLE#n Number of samples number
SP.TIME#n Trip time hhmm
SP.DURATION#n Trip duration hhmmss
SP.VUNDER#n Underrange value number
SP.VOVER#n Overrange value number
BATCHNG Batching mode OFF, AUTO, MANUAL
For setpoint commands ending with “#n”, n is the setpoint number.
Table 9-6. SETPNTS Serial Commands
