Print Formatting 35
7.0 Print Formatting
The 590 AG Indicator provides three print formats, GFMT, GPFMT, and LDFMT that determine the format of the
printed output when the
PRINT key is pressed or when a KPRINT EDP command is received.
Each print format can be customized to include up to 300 characters of information, such as company name and
address, on printed tickets. You can use the indicator front panel (PFORMT menu), EDP commands, or the
Revolution configuration utility to customize the print formats.
7.1 Print Formatting Commands
Table 7-1 lists commands you can use to format the gross and net print formats. Commands included in the format
strings must be enclosed between < and > delimiters. Any characters outside of the delimiters are printed as text on
the ticket. Text characters can include any ASCII character that can be printed by the output device.
Table 7-1. Print Format Commands
Command Description
Gross weight in displayed units
Gross weight in non-displayed units
Group count value
Head count value
Shrink value (percent)
Total head count value
Head count gross weight in displayed units – shrink applied
Head count average weight in displayed units
Total gross weight in displayed units – shrink applied
Total gross weight in displayed units
Total gross average weight in displayed units
Consecutive number
Indicator ID number
nn> New line (nn = number of termination [ or ] characters)*
nn> Space (nn = number of spaces)*
Toggle weight data format (formatted/unformatted)**
Gross weights are 10 digits in length, including sign, followed by a space and a two-digit units identifier.
Total field length with units identifier is 13 characters.
UID and consecutive number (CN) fields are 1–6 characters in length, as required.
* If nn is not specified, 1 is assumed. Value must be in the range 1–99.
** After receiving an SU command, the indicator sends unformatted data until the next SU command is
received. Unformatted data omits decimal points, leading and trailing characters.
