20 590 AG Indicator Operators Manual
3.2.2 Format Menu
DSPDIV
5D
2D
1D
MULT
0.45359
number
PRIMAR SECNDR
6SEC
4SEC
3SEC
2500MS
2SEC
1500MS
750MS
500MS
250MS
8SEC
DSPRAT
DSPDIV
1D
5D
2D
DECPNT
888880
888888
88888.8
8888.88
888.888
88.8888
8.88888
DECPNT
888880
888888
88888.8
8888.88
888.888
88.8888
8.88888
UNITS
OZ
KG
LB
T
TN
NONE
G
UNITS
TN
OZ
KG
G
T
LB
NONE
VERS PROGRM PFORMT SERIAL CALIBR CONFIG FORMAT
1SEC
Figure 3-5. Format Menu
FORMAT Menu
Parameter Choices Description
Format submenu
PRIMAR DECPNT
DSPDIV
UNITS Primary Units – Specifies the decimal position, display divisions, and units used for the
primary units. See below for submenu parameter descriptions.
Primary Units submenus
DECPNT 888888
888880
8.88888
88.8888
888.888
8888.88
88888.8 Decimal point location. Specifies the location of the decimal point or dummy zeroes in the
primary unit display. Value should be consistent with local legal requirements.
DSPDIV 1D
2D
5D Display divisions. Selects the minimum division size for the primary units displayed weight.
UNITS lb
kg
OZ
TN
T
G
NONE Specifies primary units for displayed and printed weight. Values are: lb = pound;

kg = kilogram; OZ = ounce; TN = short ton; T = metric ton; G = gram
Note
Indicators sold outside North America are configured with kg for both
primary and secondary units.
