Table 5-4. FORMAT EDP Commands
Command Description Values
PRI.DECPNT Primary units decimal position 8.88888, 88.8888, 888.888, 8888.88, 88888.8, 888888, 888880
PRI.DSPDIV Primary units display divisions 1D, 2D, 5D
PRI.UNITS Primary units LB, KG, OZ, TN, T, G, NONE
SEC.DECPNT Secondary units decimal position 8.88888, 88.8888, 888.888, 8888.88, 88888.8, 888888, 888880
SEC.DSPDIV Secondary units display divisions 1D, 2D, 5D
SEC.UNITS Secondary units LB, KG, OZ, TN, T, G, NONE
SEC.MULT Secondary units multiplier 0.00000–999999
DSPRATE Display rate
250MS, 500MS, 750MS, 1500MS, 2500MS, 1SEC, 2SEC, 3SEC,
4SEC, 6SEC, 8SEC
Table 5-5. CALIBR EDP Commands
Command Description Values
WZERO Zero calibration —
WVAL Test weight value test_weight_value
WSPAN Span calibration —
REZERO Rezero —
LC.CD Set deadload coefficient value
LC.CW Set span coefficient value
Table 5-6. SERIAL EDP Commands
Command Description Values
EDP.BAUD Baud rate 300, 600, 1200, 2400, 4800, 9600, 19200
EDP.BITS Data bits/parity 8NONE, 7EVEN, 7ODD
EDP.TERMIN Termination character CR/LF, CR
EDP.EOLDLY End-of-line delay 0–255 (0.1-second intervals)
EDP.STREAM Stream format OFF, LFT, INDUST
Table 5-7. PROGRM EDP Commands
Command Description Values
PWRUPMD Power up mode GO, DELAY
SBYDLY Standby delay 0–120
LSTMOD Last mode YES, NO
DISPMOD Display hold mode ENABLE, DSABLE
HOLD_DELTA Hold delta percent 10-99
SAMPTIME Display hold sample time 1-10 (seconds)
SHRINK Shrink percent 0.00-99.00
REGULAT Regulatory compliance NTEP, CANADA, NONE, OIML
CONSNUM Consecutive number 0–999 999
CONSTUP Consecutive number start-up value 0–999 999
UID Unit identifier 0–999 999
EDP Commands 31
