Table 5-7. PROGRM EDP Commands
Command Description Values
PWRUPMD Power up mode GO, DELAY
CNTMOD Counting Mode ENABLE, DSABLE, SPLSIZ
REGULAT Regulatory compliance NTEP, OIML, CANADA, NONE
SPLSIZ Sample size 10, 20, 50, 100, 5, PCWGT
CONSNUM Consecutive number 0–999 999
CONSTUP Consecutive number start-up value 0–999 999
DATEFMT Date format MMDDYY, DDMMYY, YYMMDD, YYDDMM
DATESEP Date separator SLASH, DASH, SEMI
TIMEFMT Time format 12HOUR, 24HOUR
TIMESEP Time separator COLON, COMMA
ACCUM Accumulator ON/OFF
ACCUM. RTZGRADS Return to zero trigger 0 - 10,000 GRADS
Table 5-8. PFORMT EDP Commands
Command Description Values
GFMT Gross demand print format
string See Section 6.0 on page 39 for detailed information
NFMT Net demand print format string
CFMT Count demand print format
string
Table 5-9. SETPNTS EDP Commands
Command Description Values
SP1 SP2
SP1.ENABLE SP2.ENABLE Setpoint enable OFF, ON
SP1.KIND SP2.KIND Setpoint kind GROSS, NET
SP1.VALUE SP2.VALUE Setpoint value number
SP1.TRIP SP2.TRIP Trip Higher, Lower, Inband, Outbnd
SP1.BNDVAL SP2.BNDVAL Band value number
SP1.HYSTER SP2.HYSTER Hysteresis number
SP1.ACCESS SP2.ACCESS Setpoint access OFF, ON
Table 5-10. DIG IN EDP Commands
Command Description Values
DIGIN1
DIGIN2 Digital input function OFF, ZERO, TARE, NT/GRS, UNITS, DSPTAR, PRINT, CLRCN,
KBDLOC, HOLD, CLRTAR, ACCUM, CLRACC, NEWID
36 420 Plus Installation Manual
