WARNING:
WARNING:
LITHIUM POLYMER BALANCE CHARGE PROGRAM
CONNECTION DIAGRAM
LITHIUM POLYMER BALANCE CHARGE PROGRAM
CONNECTION DIAGRAM
06
This diagram shows the correct way to connect your battery to the MultiPro™ charger while charging in the
balance charge program mode.
Failure to connect as shown in this diagram will damage the charger.
The main battery leads must be connected along with the balance lead connectors as shown before charging
your battery. Pay close attention to the polarity of the main battery leads.
If using crocodile clips be sure they are unable to touch together!
