VMP1 Bootstrap Loader
ID 19972, Rev. 0101 Page 5 - 13 ® PEP Modular Computers GmbH
5.2.4 Port Format
Syntax
pf [ [][/[][/[][/]]]]
Description
Without parameters specified, the current serial port settings are displayed.
• specifies the serial port. Valid values are term or ser0.
• specifies the baud rate. The values 50, 75, 110, 134.5, 150, 300, 600, 1200,
1800, 2000, 2400, 3600, 4800, 7200, 9600, 19200, 38400 and 115200 Baud can be
specified.
• specifies the bits / character. Valid values are 7 or 8.
• specifies if parity should be checked / generated. The value n specifies
none, o for odd and e for even parity.
• specifies the stopbits which will be generated. Valid values are 1 or 2.
Examples
Setting term to 300 Baud, 7 Bits/char, odd parity and 2 stopbits:
pf term 300/7/o/n
Set the bits / character field to 7 for ser0 only:
pf ser0 /7
Set the stopbits field to 2 for ser0:
pf ser0 ///2
$ $ Important!
No spaces are permitted between the options. Options must
be separated with a slash. Not all options must be specified,
but the '/' characters must be present to distinguish the differ-
ent options from each other. The sequence can be aborted
after every option.
On CPU’s without a ser0 serial connection the Bootstrap
Loader will refuse setting ser0 port parameters and will not
display ser0 port parameters.
