4.3.4.11 Board / Logic Revision Register
The Board Revision Register may be used to identify the hardware and logic status of
the board by the software. It starts with the value 0x00 for the initial board prototypes
and will be incremented with each redesign / logic release.
•
This register is READ ONLY.
Table 4-16: Board / Logic Revision Register
Register
Address
MSB
6
5
4
3
2
1
LSB
Board revision
FFE0 001e
LR3
LR2
LR1
LR0
BR3
BR2
BR1
BR0
