Kontron VMP1 - Manual (Page 47)

VMP1
ID 19972, Rev. 0101
Configuration
Page 4 - 1 ® PEP Modular Computers GmbH
Configuration
4.1 Jumper Settings .................................................................. 4 - 3
4.1.1 Bootstrap Loader / Socket Jumper J1 ......................... 4 - 3
4.1.2 RTC (Real-time clock) Calibration OutputJ2 ............... 4 - 3
4.1.3 Resistor Setting for Non-standard Socket Devices ..... 4 - 4
4.1.4 RS485 Termination (Onboard Interface Only) ............ 4 - 4
4.2 Pinouts ................................................................................ 4 - 5
4.2.1 Flash Socket Type Selection ...................................... 4 - 5
4.2.1.1 Socket Device Selection ....................................... 4 - 5
4.2.2 Serial Interface Expansion Connector (CON3) ........... 4 - 6
4.3 Board Address Map ............................................................. 4 - 7
4.3.1 Address Map Overview ............................................... 4 - 7
4.3.2 VME Address Area ..................................................... 4 - 8
4.3.3 Onboard Device Addresses ........................................ 4 - 9
4.3.4 Special Registers Overview ...................................... 4 - 10
4.3.4.1 Board Control Registers ...................................... 4 - 10
4.3.4.2 Board ID Register ............................................... 4 - 10
4.3.4.3 Software Compatibility ID .................................... 4 - 10
4.3.4.4 Memory Configuration Register .......................... 4 - 11
4.3.4.5 SDRAM Size ....................................................... 4 - 11
4.3.4.6 Flash Bank Select Register ................................. 4 - 11
4.3.4.7 Watchdog Control Register ................................. 4 - 12
4.3.4.8 Watchdog Timeout Time ..................................... 4 - 12
Chapter
4
