VMP1
Installation
ID 19972, Rev. 0101
Page 3 - 4
® PEP Modular Computers GmbH
3.1.1
Front Panel I/O Connectors
ESD Equipment!
Your VMP1 board contains electrostatically sensitive devices.
Please observe the necessary precautions to avoid damage to
your board:
•
Discharge your clothing before touching the assembly. Tools
must be discharged before use.
•
Do not touch components, connector-pins or traces.
•
If working at an anti-static workbench with professional dis-
charging equipment, please do not omit to use it.
PEP Advantage
The VMP1 is designed to be bootstrapped from the Flash device
alone.
!
Attention!
Due care should be exercised when connecting cabling in order to
avoid damage to your connected device and/or the VMP1 board.
For pinouts of the Front Panel connectors, please see Chapter 2:
Functional Description, sections 2.4.3.2 and 2.4.3.3
