VMP1 Functional Description
ID 19972, Rev. 0101 Page 2 - 4 ® PEP Modular Computers GmbH
2.2 Front Panels
Figure 2-2: Front Panels
Standard VMP1 and
VMP1 Optoisolated version
and Optoisolated version
with IO1 Module - note the
different position of the
SER 0 connector
Standard with IO1 Module
VMP1-IO1 VMP1 VMP1
W U H W U H
AB RST
LNK.
SPEED ACT.
AB RST
LNK.
SPEED ACT.
VMP1 VMP1-IO1 VMP1
W U H
AB RST
LNK.
SPEED ACT.
AB RST
LNK.
SPEED ACT.
W U H
KEY
LED colors
U = green
W = yellow
H = red
(for B&W monitors
and printouts):
