25
Table 18 — 48HJ004 Fan Performance — Horizontal Discharge Units With Standard Motor
Table 19 — 48HJ004 Fan Performance — Horizontal Discharge Units With High-Static Motor
LEGEND AND NOTES FOR TABLES 18 AND 19
LEGEND
NOTES:
1. Boldface indicates field-supplied drive required. (See Note 3.)
2. Motor drive range is 760 to 1090 rpm for standard motors; 1075 to
1455 rpm for high-static motors. All other rpms require a field-supplied
drive.
3. Values include losses for filters, unit casing, and wet coils. See page 28
for accessory/FIOP static pressure information.
4. Maximum continuous bhp is 1.20 for standard motors; 2.40 for high-static
motors. Extensive motor and electrical testing on these units ensures that
the full range of the motor can be utilized with confidence. Using your fan
motors up to the ratings shown will not result in nuisance tripping or pre-
mature motor failure. Unit warranty will not be affected. See Evaporator-
Fan Motor Data tables on page 20 for additional information.
5. Use of a field-supplied motor may affect wire sizing. Contact your Carrier
representative to verify.
6. Interpolation is permissible. Do not extrapolate.
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 526 0.06 584 0.08 656 0.12 734 0.22 818 0.25 875 0.27
1000 570 0.09 627 0.13 738 0.19 800 0.26 848 0.29 895 0.31
1100 614 0.13 670 0.16 758 0.23 812 0.29 863 0.32 914 0.35
1200 658 0.16 710 0.23 780 0.28 840 0.32 889 0.36 938 0.40
1300 703 0.20 752 0.27 808 0.32 868 0.37 916 0.41 963 0.45
1400 725 0.29 776 0.31 845 0.38 891 0.42 937 0.47 983 0.51
1500 755 0.33 816 0.38 870 0.43 924 0.48 969 0.53 1014 0.58
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.7 0.8 0.9 1.0 1.1 1.2
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 924 0.32 953 0.35 989 0.38 1028 0.42 1074 0.45 1120 0.50
1000 936 0.35 977 0.39 1020 0.44 1064 0.48 1124 0.52 1185 0.55
1100 960 0.39 1005 0.43 1052 0.49 1100 0.52 1163 0.56 1225 0.60
1200 988 0.45 1038 0.50 1076 0.53 1136 0.59 1201 0.61 1266 0.64
1300 1012 0.51 1061 0.56 1094 0.61 1172 0.65 1239 0.69 1306 0.72
1400 1027 0.56 1071 0.60 1108 0.67 1208 0.70 1278 0.75 1347 0.79
1500 1056 0.63 1097 0.68 1117 0.70 1245 0.74 1315 0.80 1385 0.85
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 584 0.08 734 0.22 875 0.27 953 0.36 1028 0.42
1000 627 0.13 800 0.26 895 0.31 977 0.39 1064 0.48
1100 670 0.16 812 0.29 914 0.35 1005 0.43 1100 0.52
1200 710 0.23 840 0.32 938 0.40 1038 0.50 1136 0.59
1300 752 0.27 868 0.37 963 0.45 1061 0.56 1172 0.65
1400 776 0.31 891 0.42 983 0.51 1071 0.60 1208 0.70
1500 816 0.38 924 0.48 1014 0.58 1097 0.68 1245 0.74
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 1120 0.54 1155 0.59 1186 0.64 1215 0.69 1240 0.73
1000 1185 0.60 1222 0.66 1255 0.71 1285 0.77 1312 0.82
1100 1225 0.65 1263 0.71 1298 0.77 1328 0.83 1357 0.88
1200 1266 0.72 1306 0.79 1341 0.86 1373 0.92 1402 0.98
1300 1306 0.79 1347 0.87 1383 0.94 1416 1.01 1446 1.07
1400 1347 0.87 1389 0.95 1427 1.03 1461 1.11 1492 1.18
1500 1385 0.96 1428 1.05 1467 1.14 1502 1.22 1534 1.30
Bhp — Brake Horsepower Input to Fan
FIOP — Factory-Installed Option
