Carrier 48HJD005-007 User Manual
Page 20
20
Table 5A — 48HJ Fan Rpm at Motor Pulley Setting With Standard Motor
*Approximate fan rpm shown (standard motor/drive).
Table 5B — 48HJ Fan Rpm at Motor Pulley Setting With High Static Motor
Table 6 — Evaporator-Fan Motor Data — Standard Motor
LEGEND
Bhp — Brake Horsepower
*Extensive motor and electrical testing on these units ensures that
the full horsepower and watts range of the motors can be utilized
with confidence. Using your fan motors up to the ratings shown in
this table will not result in nuisance tripping or premature motor fail-
ure. Unit warranty will not be affected.
Table 7 — Evaporator-Fan Motor Data — High-Static Motors
LEGEND
Bhp — Brake Horsepower
*Extensive motor and electrical testing on these units ensures that
the full horsepower and watts range of the motors can be utilized
with confidence. Using your fan motors up to the ratings shown in
this table will not result in nuisance tripping or premature motor fail-
ure. Unit warranty will not be affected.
STANDARD MOTOR*
UNIT
48HJ
MOTOR PULLEY TURNS OPEN
0
1
/
2
1
1
1
/
2
2
2
1
/
2
3
3
1
/
2
4
4
1
/
2
5
5
1
/
2
6
004
1090
1055
1025
990
960
925
890
860
825
795
760
—
—
005
1185
1150
1115
1080
1045
1015
980
945
910
875
840
—
—
006
(single-phase)
1460
1425
1385
1350
1315
1275
1240
1205
1165
1130
1095
1055
1020
006 (3-phase)
and 007
1585
1540
1490
1445
1400
1350
1305
1260
1210
1165
1120
—
—
HIGH-STATIC MOTOR
UNIT
48HJ
MOTOR PULLEY TURNS OPEN
0
1
/
2
1
1
1
/
2
2
2
1
/
2
3
3
1
/
2
4
4
1
/
2
5
5
1
/
2
6
004
1455
1423
1392
1360
1328
1297
1265
1233
1202
1170
1138
1107
1075
005
1455
1423
1392
1360
1328
1297
1265
1233
1202
1170
1138
1107
1075
006
1685
1589
1557
1525
1493
1460
1428
1396
1364
1332
1300
—
—
007
1685
1589
1557
1525
1493
1460
1428
1396
1364
1332
1300
—
—
UNIT
48HJ
UNIT
PHASE
MAXIMUM
CONTINUOUS BHP*
MAXIMUM
OPERATING WATTS*
UNIT VOLTAGE
MAXIMUM
AMP DRAW
004
Single
1.20
1000
208/230
5.4
Three
1.20
1000
208/230
5.4
460
2.4
575
2.4
005
Single
1.20
1000
208/230
5.4
Three
1.20
1000
208/230
5.4
460
2.4
575
2.4
006
Single
1.30
1650
208/230
9.7
Three
2.40
2120
208/230
6.4
460
2.9
575
2.9
007
Three
2.40
2120
208/230
6.4
460
2.9
575
2.9
UNIT
48HJ
UNIT
PHASE
MAXIMUM
CONTINUOUS BHP*
MAXIMUM
OPERATING WATTS*
UNIT VOLTAGE
MAXIMUM
AMP DRAW
004
Three
2.40
2120
208/230
6.4
460
2.9
575
2.9
005
Three
2.40
2120
208/230
6.4
460
2.9
575
2.9
006
Three
2.90
2615
208/230
7.9
460
3.6
575
3.6
007
Three
2.90
2615
208/230
6.4
460
3.6
575
3.6
