Detail #54
If only a head and sill are used, use D.L.O. + 1". If any intermediate horizontals
The glass size formulas for the 955 system are based on D.L.O. plus 1", horizontally
SECTION VII - GLASS INSTALLATION
STEP #54
HORIZONTAL GLASS SIZE FORMULA (D.L.O. + 1.000")
PAGE #38
Swing the opposing end of the glass around to align with the glass pocket.
From the interior of the system, install the glass into the deep glass pocket.
STEP #55
GLASS INSTALLATION
Shift the glass into the shallow glass pocket until there is equal glass bite
at both sides of the glass. Rest the glass on the setting blocks.
See Detail #55 below.
1
2
3
Detail #55
CONT.
7/16"
TYP.
D.L.O.
GLASS SIZE =
D.L.O.
8651
7/16" TYP.
8685 GLZ. STOP
8685 GLZ. STOP
TYP.
7/16"
and D.L.O. plus 1" or 7/8", vertically. This applies to both 1" and 1/4" glazed systems.
DPS 4/2004
are used, the formula should be D.L.O. + 7/8". See detail #54 below.
D.L.O.
GLASS SIZE = D.L.O. + 1"
TYP.
1/2"
TYP.
1/2"
8685 GLZ. STOP
D.L.O. + 7/8"
D.L.O. + 7/8"
GLASS SIZE =
955 TECHSET
VERTICAL GLASS SIZE FORMULA (D.L.O. + 1" or D.L.O. + 7/8")
