This end extends into
and over the lower glass
unit’s corner.
the vertical glazing pocket
SET IN SEALANT
HWD1
WATER DEFLECTOR
TYP. VERTICAL
GLASS UNIT BELOW
TYP. HORIZONTAL
Detail # 45
SECTION VII - GLASS INSTALLATION
1G72, 1G73,
& 2G23 OPT.
1G67 STD.
1G61
as shown in this figure.
in a small amount of sealant, to ensure
It will be necessary to set the water deflector
that it stays in place when setting the lower
Detail # 44
glass unit.
AT VERTICAL INTERMEDIATE,
HWD1 WATER DEFLECTOR
position the water deflector
Remove the paper backing and
STEP #46
PAGE #32
CONT.
DPS 12/2001
LEFT JAMB, AND RIGHT JAMB
