DAYLIGHT OPENING

2 per D.L.O. at quarter points. Install weep baffles over the holes with silicone.

Drill 1/4" diameter weep holes in the horizontal face member at 48" on center or

INTERMEDIATE HORIZONTAL FACE

SECTION IV - FABRICATION

48" O.C.

APPLY BAFFLES WITH A SMALL

AMOUNT OF SILICONE TYPE SEALANT.

Install the exterior glazing gasket into the face member at this time, (WNB9).

Be sure to add 2% to the cut length to prevent gaps at gasket intersections.

See Detail #12 above.

STEP #12

STEP #11

8553 FACE

1/4" DIA.

WEEP

HOLES

L

C

WNB9

See Detail #12 below.

Do not plug the weep holes with silicone.

15/16"

WNB9

Detail #12

(CONT.)

PAGE #16

JDA 9/2000
