1/4" GLAZING ADAPTOR FABRICATION AND PREPARATION

Butt the horizontal adaptor to the vertical and fasten with SFZ5 screws as shown.

Detail #21

SEE TOOLING DRAWING
001096 FOR END PREP

#SFZ5

Notch the #8651 horizontal glazing adaptors to clear the vertical adaptors as shown

horizontals. See detail #20 below.

in detail #21 below.

STEP #23

STEP #22

Cut the #8651 glazing adaptor to daylight opening minus 1/16" for verticals and

for SFZ5

& CNTR SINK

DRILL THRU

.128" DIA. (#30)

Detail #20

RUNS THROUGH

VERTICAL ADAPTOR

.687

8651

.125

VERTICAL ADAPTOR

ADAPTOR AROUND

NOTCH HORIZONTAL

HORIZONTAL & VERTICAL

DAYLIGHT OPENING

2" FROM END

12" O.C.

2" FROM END

12" O.C.

PAGE #21

SECTION IV - FABRICATION

CONT.

Prep the glazing adaptors for the attachment screws as shown below.

JDA 9/2000
