EFCO 955 Series - Manual (Page 20)

(2 PLACES)
THRU (1) WALL
.159 DIA. (#21) DRILL
2.250
REF.
C
L
Detail #15
DRILL JIG
1.125
2.125
H262
HORIZONTALS
THIS PREP FOR
1G67 & 2G23
.431
TO HEAD
Refer to pages #6 through #11 for the drill jigs and the drill jig guides to correctly
If horizontal intermediates are being incorporated, the verticals must be
identify the required holes to drill for the particular horizontal / shear block
1.187
1.187
prepped for the horizontal shear block attachment.
See detail #15 below to determine the horizontal location.
SECTION IV - FABRICATION
STEP #16
CONT.
PAGE #18
KDE 12/2002
being used.
955 Tech Set
