3-6 SmartSwitch ATM User Guide
Multi-level PNNI Topology PNNI Routing
Do the same on switch SWB3:
SWB3 # set pnnipglelection
NodeIndex(1) :
LeadershipPriority(0) : 205 — Highest priority in election process
ParentNodeIndex(0) : 2 — Node 2 will represent the peer group B in the parent group
InitTime(15) :
OverrideDelay(30) :
ReElectTime(15) :
SWB3 #
7. Use the show pnnipglelection command to verify that switches SWA3 and SWB3 have become
the PGLs of their respective peer groups. For example, on switch SWA3, enter the following:
SWA3 # show pnnipglelection
NodeIndex(1) :
PGL Election Information
================================================================================
Node Index : 1
Leadership Priority : 205
Parent Node Index : 2
Init Time : 15 secs
Override Delay : 30 secs
Reelect Time : 15 secs
Time Stamp : 228588
Election State : Operating as PGL — Switch SWA3 has become PGL of group A
Preferred PGL : 50:a0:39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:20:d4:28
:c1:ff:00
Peer Group Leader : 50:a0:39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:20:d4:28
:c1:ff:00
Active Parent Node Id : 48:50:39:00:00:00:00:00:00:00:00:00:00:00:01:00:20:d4:28
:c1:ff:00
SWA3 #
8. Physically connect switch SWA3 to SWB3 to establish connectivity between peer groups A and B.
9. Use the show pnnilink command to check the connectivity between the peer groups. In the
following example, show pnnilink is entered on switch SWA3 and shows a link to switch SWB3
(SWB3’s IP address is 206.61.237.23):
SWA3 # show pnnilink
Num(ALL) :
Num Port Node Remote Node Hello State Link Type
Number Index IP Addr
===========================================================================
1 7A1 1 206.61.237.20 2WayInside Lowest Level Horizontal Link
2 7A3 1 206.61.237.19 2WayInside Lowest Level Horizontal Link
3 7B1 1 206.61.237.23 CommonOut Outside and Uplink — Physical link to switch SWB3
4 -- 2 N/A 2WayInside Horizontal Link to/from LGN — Logical link between switches
SWA3 #
Note Notice that the IP address entry for the logical link between the LGNs is N/A (Not
Applicable). Logical entities do not have IP addresses.
