A-2 SmartSwitch ATM User Guide
MIB, SMI, MIB Files and Internet MIB Hierarchy Agent Support
Figure A-1 Internet MIB hierarchy
A.1.1 CSI ZeitNet Proprietary MIBs
The location of some of ZeitNet proprietary MIBs in the Internet hierarchy is shown in Figure A-2. All nodes starting
with “zn” represent Zeitnet objects.
The private ZeitNet MIB is represented by the object identifier 1.3.6.1.4.1.1295, or
iso.org.dod.internet.private.enterprise.zeitnet. The ZeitNet proprietary MIBs include the subtrees shown in Figure A-2.
tt
CCITT
0
ISO
1
root
joint
ISO/CCITT
2
org
3
DOD
6
internet
1
mgmt
2
directory
1
experimental
3
MIB
1
private
4
Label from the root to
this point is 1.3.6.1.2.1
